Tire Identification Code Embossing Electric Branding Iron Tool of Portable Rubber Hot Branding Imprinter for Tyre Hot Brander

Tire Identification Code Embossing Electric Branding Iron Tool

Tire Identification Code Embossing Electric Branding Iron Tool

Tire Identification Code Embossing Electric Branding Iron Tool has been designed to give many operating advantages and longer working life in applying tire marking. The built-in high resistance stainless steel heating rod to heating the branding die very quickly and maintain a high operating temperature, but still ensure a longer working life, clamping handle has melting depth tuning screw and precision temperature controller is visible adjustment for consistent embossing process

Tire Identification Code Embossing Electric Branding Iron Tool

Machine Description


01: Application

Tire Identification Code Embossing Electric Branding Iron Tool is professional solution on tire identification marking, date ID, serial number, logo branding, the customized branding die can be built basing on your selection, the heating block has T-slot to replacement the Date ID, codes, numbers, letters, logo you may would like, the clamping handle can precision snap the tire during hot branding process, adjustable tuning screw for adjustable grasping force and digital temperature controller both combined with practical experience to get the perfect branding effect, electric heated inner heating cores keep the brander is always ready for working

02: Parameter:

Name

Tire Identification Code Embossing Electric Branding Iron Tool

Model

KLS-280

Heating Power

300w

Plug in

110v/220v,50hz/60hz

Slot/mounting channel

1.1~1.5*6.5~7mm

Heating Rod

60*12mm

Tire branding Temperature

280~310 degree

Time of heating up

Within 10 minute

Tire branding time

30s~60s

Interchangeable Branding Die

2pcs or more as demanding

Wire Length

300cm

Max branding Length

70mm

Dimension

300*100*100

Net Weight

3kgs

Gross Weight

4kgs

03: Character:

Stainless steel heading rod built in with high resistance for quick heating up

T-slotted branding head make the Date branding die insertion a a snap

Date ID, serial number, logo, interchangeable number or letters all can be personal demanding

Rugged construction for topmost longevity

Minimal weight of this branding iron makes it easier to handle and control

04: Operation instructions

Tire Identification Code Embossing Electric Branding Iron Tool is constructed with a T Slot in which the desired branding characters, numbers, or letters can be inserted into place by pliers or hand insert if not heated, before attempting to brand, allow a few minutes for the tool to reach its operating temperature, once full heat is reached, branding is done by simple clamp the tire on the work surface while applying some pressure by tuning the melting force, set the temperature 200~300 degree in 30~60 seconds melting, you can bet a new DOT ID

05: Notice

Tire Identification Code Embossing Electric Branding Iron Tool is constructed to hold up under everyday use, and will give the user long efficient service, Tire Identification Code Embossing Electric Branding Iron Tools operate at high temperature and should be used very carefully, severe burns or fire may result if the tool is used improperly, keep branders away from combustible materials, dont place heated branders in areas where others may accidentally come in contact with them, always use the correct voltage the tool was designed for, plugging a 110 volt tool into a 240 volt circuit is extremely dangerous and will cause the brander to fail, avoid leaving the tool plugged in a for long periods of time without use because it is possible to build up and excess of heat, when in use, never rest the brander in a position with the branding head down, always use the metal stand to rest the brander on a no-combustible surface, dont strike brander against hard surface to shake off dirty and melted rubber, clean branders heating block and branding die with a brass brush

06: Important warranty

The electrical cord used in Tire Identification Code Embossing Electric Branding Iron Tool is made of a special flexible, heavy-duty industrial grade cable designed to give you many years of service, however, excessive flexing or twisting may damage the cable, when branding, never place your hand or body against the cord and strain relief, check regularly to make sure the cord is not twist due to tooling rotation and correct if necessary

Machine Uses


Tire Identification Code Embossing Electric Branding Iron Tool

Tire Identification Code Embossing Electric Branding Iron Tool can mark #1: Date ID #2: Serial Number #5: Identification Codes #6: Logo #7: Artworks #8: Theft Protective Codes #9: Numbers&Letters combination

Detailed Images


Tire Identification Code Embossing Electric Branding Iron Tool

Tire Identification Code Embossing Electric Branding Iron Tool designed branding head with a T-slot for inserting different DOT dates in versatile size, the branding dies can be inserted in a hot tool using pliers

Contact Us


Tire Identification Code Embossing Electric Branding Iron Tool can satisfy your practical branding process with customized branding dies in versatile sizes,please come to consult with our experienced sales representatives for tech verification prior to purchasing
